Din Rail Power Supplies – 30W Series
The DIN30-XX series is Tiger Powers' 30W din rail power supply series featuring a cost-effective, energy efficient solution for standard DIN-rail mounting. The products offer a high level of stability and immunity to noise, compliant with international IEC62368 standards for EMC and safety specifications meet IEC/EN61000-4, CISPR32/EN55032, UL62368, EN62368, IEC62368. These light weight AC-DC converters also have an extremely compact design for space saving and are ideal for applications such as industrial control equipment machinery and all kinds of applications in a harsh environment.
Please click link below for a full datasheet on this range
Din Rail Power Supplies – 60W Series
DIN60-XX is Tiger Powers' 60W Din Rail series featuring a cost-effective, energy efficient solution for standard DIN-rail mounting. The products offer a high level of stability and immunity to noise, compliant with international IEC62368 standards for EMC and safety sepecifitions meet IEC/EN61000-4, CISPR32, EN55032, UL62368, IEC62368 and EN62368. These light weight AC-DC converters also have an extremely compact design for space saving and are ideal for applications such as industrial control equipment machinery and all kinds of applications in a harsh environment
Please click link below for a full datasheet on this range
Din Rail Power Supplies – 100W Series
100w Din Rail Power Supplies from UK power conversion experts with decades of industry experience. Tiger Power offer a comprehensive range of din rail power supply units in a wide range of power ratings and output voltages. The DIN100-XX is Tiger Powers' 100W Din Rail Power Supply series featuring a cost-effective, energy efficient solution for standard DIN-rail mounting. The products offer a high level of stability and immunity to noise, compliant with international IEC62368 standards for EMC and safety specifications meet IEC/EN61000-4, CISPR32, EN55032, UL62368, IEC62368 and EN62368. These light weight, highly efficient AC-DC converters also have an extremely compact design for space saving and are ideal for applications such as industrial control equipment machinery and all kinds of applications in a harsh environment
Please click link below for a full datasheet on this range
- Universal 85-264VAC or 120-370VDC input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -40℃ to +70℃
- High I/O isolation test voltage up to 4000VAC (Input -output)
- Industrial product technology design
- Choice of 12V, 15V, 24V and 48V outputs as standard
- Adjustable output voltages
- Over-voltage class III (Designed to meet EN61558-1 standards)
- Low standby power consumption, high efficiency up to 90%
- Low ripple & noise
- Output short circuit, over-current, over-voltage protection
- Withstand 300VAC surge input for 5s
- DIN rail TS35X7.5/ TS35X15 mountable
- CE, UKCA and UL safety approved as standard for World use
- Highly Reliable with a 3 Year Warranty
- Supplied by UK based industry experts and manufactured at one of the largest power conversion prodoct factories in the World
Waterproof Power Supplies – 60W IP65
A range of power supplies rated to IP65 for ingress protection. The units are supplied with two M12 waterproof cable grommets for easy fit of an input and output cable. The internal power supply module has screw terminals for fast connection. 90-264vac wide range input and featuring very low leakage current, these waterproof power supplies are suitable for a wide range of applications
15W Industrial Power Supplies
- Universal 85 - 305VAC or 100 - 430VDC Input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -30℃ to +70℃
- Low standby power consumption, high efficiency
- High I/O isolation test voltage up to 4000VAC
- Low ripple & noise
- Output short circuit, over-current, over-voltage,
- Safety according to IEC/EN/UL62368, EN60335, EN61558, GB4943
- Withstand 300VAC surge input for 5s
- Over-voltage class Ⅲ (designed to meet EN61558)
- Operating altitude up to 5000m
36W Industrial Power Supplies
- Universal 85 - 264VAC or 120 - 373VDC Input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -30℃ to +70℃
- Low standby power consumption, high efficiency
- High I/O isolation test voltage up to 4000VAC
- Low ripple & noise
- Output short circuit, over-current, over-voltage,
- Safety according to IEC/EN/UL62368, EN60335, EN61558, GB4943
- Withstand 300VAC surge input for 5s
- Over-voltage class Ⅲ (designed to meet EN61558)
- Operating altitude up to 5000m
- Download full datasheet below
50W Enclosed Power Supplies
- Universal 85 - 264VAC or 120 - 373VDC Input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -30℃ to +70℃
- Low standby power consumption, high efficiency
- High I/O isolation test voltage up to 4000VAC
- Low ripple & noise
- Output short circuit, over-current, over-voltage,
- Safety according to IEC/EN/UL62368, EN60335, EN61558, GB4943
- Withstand 300VAC surge input for 5s
- Over-voltage class Ⅲ (designed to meet EN61558)
- Operating altitude up to 5000m
- Output options from 5vdc to 48vdc
- Full data sheet below
75W Industrial Power Supplies
- Universal 85 - 305VAC or 120 - 430VDC Input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -30℃ to +70℃
- Low standby power consumption, high efficiency
- High I/O isolation test voltage up to 4000VAC
- Low ripple & noise
- Output short circuit, over-current, over-voltage,
- Safety according to IEC/EN/UL62368, EN60335, EN61558, GB4943
- Withstand 300VAC surge input for 5s
- Over-voltage class Ⅲ (designed to meet EN61558)
- Operating altitude up to 5000m
- Download full datasheet below
100W Power Supply Series
100W Power Supply series from from Tiger Power is a highly efficient industrial grade power supply range. These power supplies feature a wide range 85-264vac auto adjusting input for world use. The offer very low standby power consumption and meet latest safety and efficiency standards. Supplied by one of the UKs leading providers of power supply products
Part number: TGR100-XX (refer to data sheets below)
- Universal 85 - 264vac (or 120 - 370vdc input)
- Accepts AC or DC - Dual use of same terminal
- Fanless and noiseless design
- CE , UKCA, UL safety marked
- Designed to 62368-1, EN60335, EN61558 standard
- Suitable for use on a wide range of applications
- Low ripple & noise
- High input/output isolation up to 4000vac
- Over voltage, short circuit, over current and over temperature protection
- Very low no load power consumption
- Operating altitude up to 5000M
- Compact design (for ultra compact series see TGR100B-XX next generation 100w power supplies)
100W Power Supplies Ultra Compact High Efficiency
100W Power Supply series from from Tiger Power is a highly efficient industrial grade power supply range. These power supplies feature a wide range 85-264vac auto adjusting input for world use. The offer very low standby power consumption and meet latest safety and efficiency standards. Supplied by one of the UKs leading providers of power supply products
Part number: TGR100-XX (refer to data sheets below)
- Universal 85 - 264vac (or 120 - 370vdc input)
- Accepts AC or DC - Dual use of same terminal
- Fanless and noiseless design
- CE , UKCA, UL safety marked
- Designed to 62368-1, EN60335, EN61558 standard
- Suitable for use on a wide range of applications
- Low ripple & noise
- High input/output isolation up to 4000vac
- Over voltage, short circuit, over current and over temperature protection
- Very low no load power consumption
- Operating altitude up to 5000M
- Compact design (for ultra compact series see TGR100B-XX next generation 100w power supplies)
150W Power Supply Ultra Compact High Efficiency Series
150W Power Supply Ultra Compact High Efficiency Series TGR150B-XX series from from Tiger Power is a highly efficient industrial grade power supply range. All units in this range feature high efficiency up to 92% and a very small fotprint, measuring just 99 x 97 x 30mm. Being convection cooled results in a higher reliability and more energy efficient design. Supplied by one of the UKs leading providers of power supply products
Part number: TGR150B-XX (refer to data sheets below)
- Universal 85 - 305vac (or 120 - 430vdc input)
- Accepts AC or DC - Dual use of same terminal
- Dimensions 99 x 97 x 30mm
- Fanless and noiseless design
- CE, UKCA safety marked and approved
- Designed to 62368-1, EN60335, EN61558 standard
- Suitable for use on a wide range of applications
- High input/output isolation up to 4000vac
- Over voltage, short circuit, over current and over temperature protection
- Meets latest efficiency legislation & very low no load power consumption
- Operating altitude up to 5000M
- Slimline design
